| 角接觸球軸承, 精密, DB, contact angle 25° | |||||||||||
| 公差 , see also text / text 718 (SEA) series | |||||||||||
| 預壓, see specific product, see also text, unmounted, and text, mounted / text 718 (SEA) series | |||||||||||
| Recommended fits, shafts, housings | |||||||||||
| 軸和軸承座公差 | |||||||||||
|
|||||||||||
| 主要數據尺寸 | 基本負荷額定值 | 疲勞負荷限值 | 可達到的速度 | 體積 | 型號 | ||||||
| 動態 | 靜態 | 當潤滑與 | SKF | SNFA | |||||||
| 油脂 | 滴油潤滑 | Listing of both SKF and SNFA designations means that | |||||||||
| d | D | B | C | C0 | Pu | ||||||
|
|
|||||||||||
| mm | kN | kN | r/min | kg | - | ||||||
|
|
|||||||||||
| 85 | 130 | 22 | 34,5 | 39 | 1,6 | 11000 | 18000 | 0,9 | 7017 DB/P7 | - | |
我公司特價供應以下型號產品： 7234BDB 角接觸球軸承 NN3022 圓柱滾子軸承 SL182217 圓柱滾子軸承 UCP328 帶座外球面球軸承 63/28N 深溝球軸承 7303AC/DF 角接觸球軸承 24040-E1-K30 調心滾子軸承 F626ZZ 深溝球軸承 SNL3056G 剖分立式軸承座
